TROUBLESHOOTING
Issue
No sound.
Intermittent sound or distorted sound.
Lack of range.
Cause
Source malfunction. Improper connection. Multiple
transmitters are set to the same operating channel.
Transmitter has gone out of range. Transmitting
through metal wall. Unknown source of RF in local
area.
Improper or lack of antenna connection. Multiple
transmitters are set to the same operating channel.
Unknown source of RF in local area..
System not turned on. Source malfunction. Improper
connection or improper channel selection. Expired
battery.
Power, Signal Source, Cables or RF
Signal Source, Cables or RF
RF
See Solution...
Power
Make certain that the transmitter and receiver are receiving sufficient power. The receiver requires 9V DC at 500ma. The
transmitter requires 9V DC via alkaline 9V battery. Check the battery status indicator on the transmitter and replace if neces-
sary.
Signal Source
Make certain that the source is operating as desired by checking source power, signal levels and connections. If necessary,
bypass digital wireless transmission and check the source directly.
Cables
Make certain that all connections and cables are in working order.
RF
Turn all known transmitters off. Check to see if the red RF LED on the receiver’s front panel is lit. If it is not lit, then the receiver
is not detecting the presence of RF signal on the currently selected channel. If it is lit, then the receiver is detecting the
presence of unknown RF signal. Check to see if any of the green Receiver LEDs are lit. If any are lit, then the receiver is
detecting the presence of another X2 transmitter set to the same channel. Locate this unit and either turn it off or switch chan-
nels. If none of the green Receiver LEDs are lit, then the receiver is detecting confirmed RF signal from a source other than an
X2 transmitter. Change the channel and repeat these steps to locate a clear channel.
11
