10. LOADING THE PAPER
STEP 1: Gently pop the printer cover’s latch; then pull the cover upward to open the
paper roll cover (Figure 10).
STEP 2: Load a roll of thermal paper into the printer. Please ensure the printing-side of
the paper will feed out facing the operator.
STEP 3: Close the cover by pressing on the center of the printer cover. Use the serrated
bar to tear off any excess paper.
Figure 10
11. INSTALL THE STRAP
Align two ends of strap pin to the notches on AT-170 rear cover as Figure 11-1.
Figure 11-1
Press downward the strap pin into the notches, than pull another pin of the strap to
install another side as Figure 11-2.
Note: After pressing the pin, make sure it is fixed into the notch of AT-170 as Figure
11-3.
