XAG R150 - Emergency Stop

www.xa.com/en 3
Sprayer Connector
Sprayer Holder
Jet Sprayer Control Module
Peristaltic Pump
Vibration Damper
Figure 3: Module Structure in Liquid Pump Control Box
Emergency Stop
Each time before you turn on the power, make sure the red emergency stop button is not pressed; in
case of emergency while driving, press the emergency stop button, and the braking device will cut o󽗈
the power and stop the vehicle. Gently rotate the emergency stop button and it will pop up.
Pressing the emergency stop button only cuts o󽗈 the power supply to the vehicle motor, not the jet
sprayers. Before you attempt any cable work on the sprayers, be sure to 󽗉rst power down the smart
battery.
Note
