XAG R150 - Vehicle Assembly; Assemble Jet Sprayer

www.xa.com/en4
Inspect underneath the sprayers to distinguish between the left unit and the right one, as shown in
the 󽗉gure below: the arrow points to the vehicle front, L stands for left, and R stands for right.
Note
Vehicle Assembly
Assemble jet sprayer
Fix the left and right jet sprayers on the vehicle and tighten the 󽗉xing screws (M8*20).
