Front Panel (AC End)
2–5
➄
➄➄
➄
AC Receptacle Delivers 15 amps (approximately 1700 watts) of
continuous AC power. This is a grounded outlet with a 15 amp
circuit breaker. For full output power, you need to make a permanent
hardwire connection.
➅
➅➅
➅
Circuit Breaker for AC receptacle
➆
➆➆
➆
Knockouts for AC wiring
➇
➇➇
➇
Remote Control Jack The jack allows you to connect the remote
On/Off switch.
➈
➈➈
➈
Ventilation Openings
➉
➉➉
➉
Mounting Flanges
Feature Description
