Specifications
A–2
Electrical Performance (Inverter)
Physical (Inverter)
Dimensions (Remote On/Off Switch)
Specifications are subject to change without notice.
Output power at 77º F (25º C) ambient
and 12 Vdc input:
• 5 minutes
• Continuous power
3000 W
2500 W
Output voltage 115 Vac RMS ±5%
Output waveform Modified sine wave (quasi-
square)
Output frequency 60 Hz ±0.01%
Input voltage 10–15 Vdc
Low battery alarm Audible, 10.7 V
Low battery cutout 10.0 V
Efficiency Approximately 85–90%
No load current draw <0.6 A
Length 18.5 inches (47 cm)
Width 8 inches (20.5 cm)
Height 6.25 inches (16 cm)
Weight 20 lb (9 kg)
Length 4.25 inches (10.80 cm)
Width 2.5 inches (6.35 cm)
Depth 0.7 inches (1.8 cm)
Cable Length 20 ft (6 m)
