975-0529-01-01 21
Specifications
Note: Specifications are subject to change without prior notice.
Physical and Environmental Specifications
Length × Width × Height
• PROwatt SW 600
• PROwatt SW 1000
• PROwatt SW 2000
12.2×8.7×3.5 inch. (31×22×8.9 cm)
14×9×3.5 inch. (35×22×8.5 cm)
13.8×11.8×3.9 inch. (35×30×10 cm)
Weight
• PROwatt SW 600
• PROwatt SW 1000
• PROwatt SW 2000
6.5 lbs. (3.0 kg)
7.2 lbs. (3.3 kg)
10.6 lbs. (4.8 kg)
Operating temperature 32–104 °F (0–40 °C)
DC Input
600 1000 2000
Input power (max at full load) 720 VA 1200 VA 2400 VA
Input current
(max at full load)
60 A 93 A 200 A
Input voltage range 10.5–15.5 Vdc
Low battery alarm Audible, 11 V
Low battery cutout 10.5 V
AC / USB Output
600 1000 2000
Peak power (5 minutes) 600 W 1000 W 2000 W
Continuous power 540 W 900 W 1800 W
Surge power 1200 W 2000 W 3000 W
Output current (continuous) 4.6 A 7.5 A 15 A
Output current (max) 5.8 A 9.6 A 19.2 A
No load current draw < 600 mA < 600 mA < 800 mA
Output voltage (nominal) 120 Vac RMS ±5%
Output voltage range 104–127 Vac
Output waveform True sine wave
Output frequency 60 Hz ±0.5Hz
Efficiency Approximately 85–90%
USB Output 5 Vdc, 500 mA
Regulatory Approvals
UL 458 5th edition Power Converters/Inverters and Power Converter/
Inverter Systems for Land Vehicles and Marine
Crafts
CSA 107.1-01 General Use Power Supplies
FCC Part 15, Class A Electromagnetic Compatibility (EMC)
AC / USB Output
600 1000 2000
