Xerox Color C60 Series - Electrical Requirements; Space Requirements; Service Space Envelope

Installation Xerox Color
®
C60/C70
Customer Expectation and Installation Guide 24
HCF + IOT + IFM + Booklet Maker Fin (D5)
+ SQFT
144.4”
3667.8mm
31.6”
803.5mm
54.8”
1391.5mm
1273 lbs
(64+578+110+286+ 235)
OHCF + IOT + IFM + Booklet Maker Fin
(D5) + SQFT
151.8”
3855.7mm
31.6”
803.5mm
54.8”
1391.5mm
1561 lbs
(352+578+110+286+ 235)
2T OHCF + IOT + IFM + Booklet Maker Fin
(D5) + SQFT
151.8”
3855.7mm
31.6”
803.5mm
54.8”
1391.5mm
1627 lbs
(418+578+110+286+ 235)
HCF + IOT + IFM + CZ Folder + Booklet
Maker Fin (D5) +SQFT
152.4”
3870.0mm
31.6 ”
803.5mm
54.8”
1391.5mm
1361 lbs
(64+578+110+88+286+235)
OHCF + IOT + IFM + CZ Folder + Booklet
Maker Fin (D5) +SQFT
159.8”
4058.9mm
31.6 ”
803.5mm
54.8”
1391.5mm
1649 lbs
(352+578+110+88+286+235)
2T OHCF + IOT + IFM + CZ Folder +
Booklet Maker Fin (D5) + SQFT
159.8”
4058.9mm
31.6 ”
803.5mm
54.8”
1391.5mm
1715 lbs
(418+578+110+88+286+235)
OHCF + IOT + IFM + GBC + Booklet Maker
Fin (D5) + SQFT
163.8”
4160.5mm
31.6”
803.5mm
54.8”
1391.5mm
1751 lbs
(352+578+110+190+286+ 235)
2T OHCF + IOT + IFM + GBC + Booklet
Maker Fin (D5) + SQFT
163.8”
4160.5mm
31.6”
803.5mm
54.8”
1391.5mm
1817 lbs
(418+578+110+190+286+ 235)
OHCF + IOT + IFM + GBC + CZ Folder +
Booklet Maker Fin (D5) + SQFT
171.8”
4343.4mm
31.6 ”
803.5mm
54.8”
1391.5mm
1839 lbs
(352+578+110+190+88+286+235)
2T OHCF + IOT + IFM + GBC + CZ Folder
+ Booklet Maker Fin (D5) + SQFT
171.8”
4343.4mm
31.6 ”
803.5mm
54.8”
1391.5mm
1905 lbs
(418+578+110+190+88+286+235)
Electrical Requirements
Ground Fault Protection is provided which meets Xerox internal safety requirements and exceeds the Industry Standards for Information Technology
Equipment. A single power cord (see above) is required for the C60/C70 series
* Note: Please Refer to Detailed Specifications Section on page 3 for appropriate electrical requirements.
Space Requirements/ Service Space Envelope
Service Envelope for the Xerox® Color C60/C70 Printer
The dimensions listed below provide the overall service space required, including the space to the nearest obstruction. The dimensions reflect both
typical and hallway installations and are absolute minimums.
A minimum of 24 inches (609.6 mm) should be maintained between the back of the machine (Note: not the Xerox Integrated Fiery Color Server, or the
Free-Flow Integrated Server if installed) and wall. Installation of the 1- or 2- Tray Oversize High Capacity Feeder and / or Standard Finisher or Business
Ready Booklet Maker Finisher results in a stationary system installation.
A
FIN
IOT
OHCF
D2
D1
C
B
IOT = Print Engine w/UI and UI Mtg. BR Booklet Maker finisher
OCT = Offset Catch Tray Standard finisher = D4 Finisher
HCF = High Capacity Feeder Booklet Maker finisher = D5 Finisher
OHCF = Oversize High capacity feeder (1T/2T) CZ Folder = CZ Folder Option
IFM = Interface module GBC = GBC Hole Punch Unit
BR Fin = Business Ready Finisher SQFT = Square Fold Trimmer
