Detailed Specifications Xerox Color
®
C60/C70
Customer Expectation and Installation Guide 3
Operating Environment
Operating
Environment
C60/C70
Required Temperature
Range
50° to 82° F (10° to 28° C)
Required Relative Humidity
15% to 85% RH
Altitude (above sea level)
Max of 8,200 (2,500 meters)
Sound Power Levels
(Base Configuration)
Operating: 7.55 LwAd(B)
Standby: 5.17 LwAd(B)
Sound Pressure Levels
(Base Configuration)
Operating: 57.4 LpAd(dBA)
Standby: 34.7 LpAd(dBA)
Electrical Requirements
Electrical
C60/C70
North America
Voltage : 110-127 VAC +/- 10%
Frequency: 50/60 Hz +/- 3%, 20 A
Europe / Asia /
South America /
Africa
Voltage : 220-240 VAC +/- 10%
Frequency: 50/60 Hz +/- 3%, 10 A
NA Specific Power Requirements:
C60/C70
Line Option
Sole Use (not required but
recommended)
Voltage
110-127
Amperage
20
Cycles
60 Hz, Single Phase
Xerox Receptacle Part Number
600S3703
Receptacle NEMA Part Number
5-20R
Power Cord Length
8.5ft.
Receptacle Diagram
The Xerox Color C60/C70
requires the use of a 20-ampere
outlet, which is standard in most
modern office buildings. Consult
the diagram (right side) to
confirm the existence of this
outlet in the proposed
installation space.
EU Specific Power Requirements:
C60/C70
Line Option
Sole Use (not required but
recommended)
Voltage
220-240
Amperage
10
Cycles
50 Hz, Single Phase
Receptacle
The Xerox Color C60/C70 requires
the use of a 10-ampere outlet,
which is standard in most modern
office buildings. Consult with local
service to determine the country
specific receptacle and confirm the
existence of this outlet in the
proposed installation space.
Power Cord Length
8.5ft.
Accessories Requiring External Power Source
Conv. Stapler
(120V 15 A) / (220V 10 A
Print Server
(120V 15 A) / (220V 10 A
Monitor
(120V 15 A) / (220V 10 A
OHCF (1- or 2- tray)
(120V 15 A) / (220V 10 A)
IFM
(120V 15 A) / (220V 10 A
Standard Finisher
(120V 15 A) / (220V 10 A)
Booklet Maker Finisher
(120V 15 A) / (220V 10 A)
GBC Advanced Punch
(120V 15 A) / (220V 10 A)
Square-Fold Trimmer
(120V 15 A) / (220V 10 A)
C/Z Folder
(120V 15 A) / (220V 10 A)
Spectrophotometer powered
through USB port
Feature Specifications
Print
C60/C70
First Print Out Time
3
A4 LEF Simplex Color 10.4 seconds /
Black-and-white 8.5 seconds
Resolution
Up to 2400 x 2400 dpi, 256 shades of gray
Registration
Printing registration specifications for 8.5 x
11” (A4):
 ±0.7 mm (side 1-2), along the lead edge
from Trays 1-4
 ±1.2mm (side 1-2) along the side edge
from Trays 1-4
 Skew along Lead Edge from Bypass
tray skew is ±1.5mm.
Max Printable Area
The Xerox® Color C60/C70 will reproduce
11” x 17” full bleed when printing on 12” x
18” or 13” x 19” paper and A3 full bleed
when printing on SRA3 paper. The
maximum length images (480mm) are
only produced on media 19” long. On all
media there is a Lead Edge deletion of
4mm and a Trail Edge deletion of 4mm.
Side edge deletion is 3mm except for 13”
x 19” media. On 13” x 19” media the side
deletion is 3.5mm.
Copy
Max Image Area
297mm x 432mm 11.69” x 17”
Guaranteed Image Quality Area:
297mm x 432mm 11.69” x 17”
Print
Max Image Area
323mm x 480mm 12.72” x 18.90”
Guaranteed Image Quality Area:
317mm x 480mm 12.48” x 18.90”
Print Features
Optional:
PostScript Kit
Adobe PostScript printing (includes a
small plug-in card)
Standard:
 Print from USB
 Booklet Creation
 Store and Recall Driver Settings
120 V 20A
NEMA 5-20R

Xerox Color C60 Series Specifications

General

Print Speed	Up to 60 ppm color / 65 ppm black-and-white
Print Resolution	2400 x 2400 dpi
Monthly Duty Cycle	Up to 300, 000 pages
Copy Resolution	600 x 600 dpi
Duplex Printing	Automatic
Printer Type	Laser
Connectivity	10/100/1000Base-T Ethernet, High-Speed USB 2.0
Paper Sizes	A3, A4, A5, A6, B4, B5
First-Print-Out Time, Printing	As fast as 5.5 seconds
Functions	Print, Copy, Scan
Mobile Printing	Apple AirPrint, Xerox Print Service Plug-in for Android, Mopria
