General Procedures / Information
FaxCentre F110 12/04 6-29
Description of Test for Service
INIT Testmode (Test-Code 100)
This function is for initializing the TEST MODE if the FaxCentre F110 was in USERMODE.
Input Code 100 and then the parameter 00.
Flow
Pass:
No errors occurred during Init Testmode
Resultbyte:
00 … Test done and OK
FF … Test not done
80 … Operator pressed <STOP>
XX … Error code
Remark:
Initialize Toner counter to 20% for making printing tests.
Table 1:
Step Status Operator UUT Display Remarks
1 Is in TEST MODE TESTMODE
2 Enter Command Keypad: 100
3 Receive Command,
clears all buffers,
initialized all relevant drivers
and variables,
set all test to FF (means
tests not done)
ENTER TEST 100
4 OK Set Resultbyte to 00 100 TESTMODE 00
5 NOK Set Resultbyte to XX 100 TESTMODE XX XX…Errorcode
To Next Page
