Xerox FaxCentre F110 - REP 4 Scanner CIS Removal

Repairs/Adjustments
4-6 12/04 FaxCentre F110
REP 4 Scanner CIS Removal
Parts List on PL 3
1. Perform REP 3.
2. Press and remove the scanner clip.
Figure 1
3. Lift the CIS carefully.
4. Disconnect the CIS cable.
Figure 2
5. Check the CIS guide.
Scanner Clip
CIS cable
