Xerox FaxCentre F110 - REP 3 Upper Guide Assembly Removal

Repairs/Adjustments
FaxCentre F110 12/04 4-5
REP 3 Upper Guide Assembly Removal
Parts List on PL 2
1. Perform REP 2.
2. Press the left guide.
3. Lift up the left side of the Upper Guide Assy, to unclip the left hinge.
4. Move the part to the left to unclip the right hinge.
Figure 1
