General Procedures / Information
6-40 12/04 FaxCentre F110
8. Following windows can appear on the PC screen (see Figure 1 and Figure 2).
Figure 1
No “USB MFL/C5 device detected”, means device not connected to PC or connected but without
power or.
Figure 2
“MFL/C5 ready for upload” means the device is ready for firmware upgrade
9. Press the Browse Button to select the location of the Firmware Binary file
10. Press the Upload Button and the upload will start.
Figure 3
You will get the message above in case of a successfully upload (see figure 3).
After a while the device will continue with a reboot and starts with the easy install procedure, GP
16.
11.Go through the easy install procedure, GP 16, to finish the update process.
12.Make a “ White Reference (Menu * W) “ adjustment.
