General Procedures / Information
FaxCentre F110 12/04 6-55
A line is 328.95mm this means 7770 dots at 600dpi. As the video clock is 1/8 the main clock, the
period of the PWMs for PCLK and VDO1 is 7770x8=62160 mainclock cycles or 15540 base clock
cycle. If the main clock is set to 92MHz, it gives 675.65us per line.
The motor period is Tmotor=675.65/1.5= 450,43us which gives 2220.11Hz. The motor needs 6
clock cycle for a complete round. The clock is an output of the PWM regulator.
