Xerox Nuvera 120 MX Operator's Manual

Jam Detection
Xerox Production Stacker 5-3
Operator Manual
Location of the Baffles
Clearing Stray Sheets
Warning: Do Not attempt to clear stray sheets around or behind the Stacker Tray when it
is in motion!
In case stray sheets drop behind the Stacker Tray use the following process to clear the area.
2. Pause the Xerox Nuvera printer at the Control Console.
3. If the Stacker Tray is out and full, unload the stack.
4. If the Stacker Tray is raised and better access is needed, press the Stacker Unload button to
start lowering the Stacker Tray.
5. Press the Stacker Unload button again when it reaches the low position to stop the
retraction. If the Stacker Tray is already at the low position, proceed to the next step.
6. Open the top cover of the stacker.
1
4
6
2
3
1
4
6
2
3
