Xerox Phaser 6120 Replacement Manual

Replacing Consumables
81
3 Open the front cover and check that the toner cartridge to be replaced has
rotated to the exchange position.
" You can identify the toner cartridge by the color of the handle and
by the letter molded into the handle: C (cyan), M (magenta),
Y
(yellow), and K (black).
4 Pull the handle on the toner cartridge toward you, and then pull the toner
cartridge up to remove it.
" Do not manually rotate the toner cartridge carousel. In addition, do
not rotate the carousel with force; otherwise, it may be damaged.
CAUTION
Dispose of the empty toner cartridge according to your local regulations. Do
not burn the toner cartridge.
5 Prepare a new toner cartridge.

Xerox Phaser 6120 Specifications

General

Color	Yes
Print technology	Laser
Time to first page (black, normal)	13 s
Time to first page (color, normal)	22 s
Print speed (black, normal quality, A4/US Letter)	20 ppm
Print speed (color, normal quality, A4/US Letter)	5 ppm
Internal memory	128 MB
Processor model	300 MHz, 32 bit RISC
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
I/O ports	USB
Power requirements	200 – 240 VAC / 100 – 127 VAC 50/60 Hz
Networking features	Ethernet/Fast-Ethernet
Non-operating relative humidity (non-condensing)	10 - 85 %
Total input capacity	200 sheets
Maximum input capacity	500 sheets
Printer fonts	PostScript
Maximum duty cycle	35000 pages per month
Number of PostScript fonts	139
Power consumption (printing)	380 W
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	442 x 395 x 341 mm
