Xerox Phaser 8560 Service Manual

Phaser 8400/8500/8550/8560 Color Printer Service Manual 3-5
Error Messages and Codes
6.08 N/A Soft IDE drive general failure. Reseat IDE
cable and power cable. If problem
persists, replace the IDE drive. The
printer will work without the IDE drive.
6.808
07.01 Flutter only Soft Control Panel link is invalid or bad
parity.
16.1
07.02 Flutter only Soft Control Panel version mismatch. 16.2
08.01 Flutter only Soft Control Panel failed to initialize. 16.3
09.01 Flutter only Soft Control Panel data path failure. 16.4
10.01 Flutter then 10 blinks Hard PLD power control link down. 33.1
10.02 Flutter only Soft PLD power control link invalid,
mismatch error.
33.2
11.01 Flutter then 11 blinks Hard EEPROM read failure.
1. Check EEPROM orientation.
2. Replace EEPROM.
12.1
11.02 Flutter then 11 blinks Hard EEPROM write failure.
1. Check EEPROM orientation.
2. Replace EEPROM.
12.2
11.03 Flutter then 11 blinks Hard EEPROM re-read failure.
1. Check EEPROM orientation.
2. Replace EEPROM.
12.3
11.04 Flutter then 11 blinks Hard EEPROM data failure, mismatch error.
1. Check EEPROM orientation.
2. Replace EEPROM.
12.4
12.xx Flutter only Soft Configuration card test failure.
1. Check card orientation.
2. Reseat then replace the
configuration card.
NOTE Printer will work as a base model
(without networking) without the
configuration card (8400 only).
13.01 Flutter then 13 blinks Hard PHY reset failure, reset stuck low. 2.1
13.02 Flutter then 13 blinks Hard PHY ID error, mismatch error. 2.2
14.xx Flutter then 14 blinks Hard USB errors, N2280 netchip read, write,
and mismatch errors, POST hard
errors.
19.1
15.01 Flutter then 15 blinks Hard CPU interrupt error. 19.3
15.02 Flutter then 15 blinks Hard CPU interrupt error, missing CPU
interrupts.
19.4
15.03 Flutter then 15 blinks Hard CPU interrupt error, IRQ spurious
assertion.
19.5
POST Error Reporting Blink Pattern Definition Table (Continued)
8400
Error
Code
PS, PE and Control
Panel LEDs (for
8400)
POST
Error
Type Description
8500/
8550/8560
Error Code

Xerox Phaser 8560 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (color, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	3 ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Maximum internal memory	1 MB
Sound power level (standby)	33 dB
Sound pressure level (printing)	54 dB
Maximum duty cycle	85000 pages per month
Number of print cartridges	4
Page description languages	PCL 5c
Maximum input capacity	625 sheets
Paper tray 2 input capacity	525 sheets
Multi-Purpose tray input capacity	100 sheets
Power requirements	110 - 240 V, 50/60 Hz
Networking features	10/100BaseTX
Standard media sizes	140 x 216 mm - 216 x 356 mm
Power consumption (active)	230 W
Compatible operating systems	Linux, Mac OS X 10.2 +, Novell NetWare 3.x +, Windows 2000 +
Envelopes sizes	C5, DL
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	IPv6
Sustainability certificates	ENERGY STAR
Power consumption (PowerSave)	43 W
Storage temperature (T-T)	-30 - 60 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Dimensions (WxDxH)	406 x 533.4 x 368 mm
