For Windows, Booklet Layout is on the Page Layout tab. Page Layout is on the Document Options
tab.
For Macintosh, in the Print window, in Xerox Features, Booklet Layout is on the Paper/Output list.
When you print booklets using the Windows PostScript or Macintosh driver, you can specify the gutter
and creep.
Gutter: Specifies the horizontal distance in points between the page images. A point is 0.35 mm
(1/72 in.).
Creep: Specifies how much the page images shift outward in tenths of a point. Shifting
compensates for the thickness of the folded paper, which can cause the page images to shift
outward slightly when folded. You can select a value from zero to 1 point.
Gutter
Creep
SSeelleeccttiinngg FFiinniisshheerr OOppttiioonnss
With the optional finisher option installed on the printer, you can request stapled documents right
from your desktop computer. The stapler can staple up to 30 sheets of 105 g/m
2
.
1. From the Printing Options tab, locate the Finishing option, then select 1 Staple.
2. Click OK.
The stapled prints are delivered to the finisher unit.
SSeelleeccttiinngg MMaaiillbbooxx OOppttiioonnss
With the optional mailbox option installed on the printer, you can send prints to a specific mailbox
bin right from your desktop computer.
1. From the Printing Options tab, locate the Output Destination option, then select one of the
mailbox bins.
2. Click OK.
The prints are delivered to the selected mailbox bin.
UUssiinngg SSppeecciiaall PPaaggeess
The Special Pages options control how covers, inserts, and exception pages are added to your printed
document.
Xerox
®
VersaLink
®
C505 Color Multifunction Printer
User Guide
139
