Xerox VersaLink C505 User Manual

12. If needed, set the printer as the default printer.
Note: Before selecting Share Printer, contact your system administrator.
13. To complete the installation, click Finish, then click Close.
IInnssttaalllliinngg tthhee PPrriinntt DDrriivveerrss ffoorr aa WWiinnddoowwss UUSSBB PPrriinntteerr
1. Insert the Software and Documentation disc into the appropriate drive on your computer.
Note: If the Software and Documentation disc is not available, download the latest
drivers from www.xerox.com/office/VLC505drivers.
If the installer does not start automatically, navigate to the drive, and double-click the Setup.exe
installer file.
2. Click Install Software.
3. At the License Agreement, select I Agree, then click Next.
4. To install the printer support software, select Software, then click Next.
5. In the Software and Documentation window, clear the check box for any unnecessary options.
6. Click Next.
7. To complete the installation, click Finish.
IInnssttaalllliinngg tthhee DDrriivveerrss aanndd UUttiilliittiieess ffoorr MMaacciinnttoosshh OOSS XX
1. Insert the Software and Documentation disc into the appropriate drive on your computer.
2. Open Xerox
®
Print Drivers 3.xx.x.dmg/.pkg as needed for your printer.
3. To run Xerox
®
Print Drivers 3.xx.x.dmg/.pkg, double-click the appropriate file name.
4. When prompted, click Continue.
5. To accept the license agreement, click I Agree.
6. To accept the current installation location, click Install, or select another location for the
installation files, then click Install.
7. If prompted, enter your password, then click OK.
8. From the list of discovered printers, select your printer, then click Next.
9. If your printer does not appear in the list of discovered printers:
a. Click the Network Printer Icon.
b. Type the IP address of your printer, then click Continue.
c. Select your printer in the list of discovered printers, then click Continue.
10. If your printer was not detected, verify that the printer is powered on and that the Ethernet or
USB cable is connected properly.
11. To accept the print queue message, click OK.
12. Select or clear the Set Printer as Default and Print a Test Page check boxes.
13. Click Continue, then click Close.
Xerox
®
VersaLink
®
C505 Color Multifunction Printer
User Guide
53
Getting Started

Xerox VersaLink C505 Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	9 s
Print margins (top, bottom, right, left)	4 mm
Print speed (black, normal quality, A4/US Letter)	43 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 400 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7 s
Time to first copy (color, normal)	5 s
Copy speed (black, normal quality, A4)	43 cpm
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Input color depth	24 bit
Maximum scan area	216 x 356 mm
Output color depth	8 bit
Scan speed (color)	40 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	69 ppm
Duplex scan speed (color)	52 ppm
Document formats supported	PDF, XPS
Optical scanning resolution	600 x 600 DPI
Faxing	No
Digital sender	-
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	120000 pages per month
Recommended duty cycle	0 - 8000 pages per month
Number of print cartridges	4
Page description languages	HP-GL, PCL 5e, PCL 6, PDF 1.7, PostScript 3, TIFF, XPS
Printer management	Apple Bonjour, Email alerts, Xerox CentreWare Web, Xerox Embedded Web Server
Wi-Fi standards	802.11a, 802.11b, 802.11g
Cabling technology	10/100/1000Base-T(X)
Security algorithms	256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Authentication method	Convenience Enabled
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)	TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD
Internal memory	4096 MB
Processor cores	2
Processor frequency	1050 MHz
Sound power level (standby)	33.6 dB
Sound pressure level (printing)	56.2 dB
Paper input type	Paper tray
Total input capacity	700 sheets
Total output capacity	500 sheets
Maximum input capacity	1250 sheets
Total number of input trays	1
Auto document feeder (ADF) input capacity	150 sheets
Auto document feeder (ADF) output capacity	100 sheets
Custom media width	76.2 - 216 mm
Custom media length	127 - 356 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 220 g/m²
Non-ISO print media sizes	Legal
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight	60 - 128 g/m²
Auto Document Feeder (ADF) media weight (imperial)	16 - 45 lbs
Display	LCD
Control type	Touch
Product color	Black, Blue, White
Market positioning	Business
Standard interfaces	Ethernet, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	89 W
Power consumption (PowerSave)	0.9 W
Power consumption (average operating)	730 W
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Linux operating systems supported	Fedora 25, RedHat EL Linux, openSUSE 13.2
Other operating systems supported	HP-UX 11.31, IBM iSeries, Solaris 11
Server operating systems supported	Windows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Sustainability certificates	ENERGY STAR
Certification	CE
Package depth	655 mm
Package width	594 mm
Package height	789 mm
Package weight	43000 g
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	502.8 mm
Width	470 mm
Height	643.7 mm
Weight	35000 g
