LLooaaddiinngg EEnnvveellooppeess iinn TTrraayy 11
1. To remove the tray from the printer, pull out the tray until it stops. Lift the front of the tray
slightly, then pull it out.
2. Remove any paper in the tray.
3. Adjust the paper length and width guides as illustrated.
4. Load envelopes in the trays with the flaps closed, flap-side down, and the short edge leading into
the printer.
Note: Do not load more than 50 envelopes into the tray, up to 45 mm (1.8 in.) in height.
5. Adjust the width guides until they touch the edges of the envelopes.
6. Slide the tray all the way into the printer.
174
Xerox
®
VersaLink
®
C605 Color Multifunction Printer
User Guide
Paper and Media
