Xerox WorkCentre 5222 Service Manual Field

June, 2008
2-1
WorkCentre 5222, 5225, 5230
Status Indicator Raps
Revision
127 Software
127-310 ESR Task RAP ................................................................................................. 2-699
127-314 WSD Print S/W Fail RAP .................................................................................. 2-699
127-353 LPD Software RAP ........................................................................................... 2-700
127-396 Mail I/O Software RAP...................................................................................... 2-700
127-398 IPP Software RAP............................................................................................. 2-701
127-399 JME Software RAP ........................................................................................... 2-701
133 Fax Control
133-210 Fax Parameter RAP.......................................................................................... 2-703
133-211 Fax Parameter Value Invalid RAP .................................................................... 2-703
133-212 Fax Read Error- No Data RAP.......................................................................... 2-704
133-213 Fax Read Error- Invalid Data RAP.................................................................... 2-704
133-214 Fax USB Initializing RAP .................................................................................. 2-705
133-215 Fax USB Device RAP ....................................................................................... 2-705
133-216 Fax USB Host Fatal RAP.................................................................................. 2-706
133-217 Fax Manager Short of Memory RAP................................................................. 2-706
133-218 Fax Card Message Library Short of Memory RAP............................................ 2-707
133-219 Fax Work Memory RAP .................................................................................... 2-707
133-220 Fax Control Task RAP ...................................................................................... 2-708
133-221 Fax Card Boot RAP .......................................................................................... 2-708
133-222 Fax Card does not respond intervalley RAP..................................................... 2-709
133-223 Fax Card Reset RAP ........................................................................................ 2-709
133-224 Controller ROM Fax Card ROM RAP ............................................................... 2-710
133-226 Country Code RAP ........................................................................................... 2-710
133-280 Fax Option Slot 1 Board RAP ........................................................................... 2-711
133-281 Received unknown message RAP.................................................................... 2-711
133-282 Fax Card Download RAP.................................................................................. 2-712
133-283 Fax Report Mailbox RAP .................................................................................. 2-712
133-700 Staple/Punch Cancelled RAP ........................................................................... 2-713
133-710 Tray Select Fail RAP......................................................................................... 2-713
134 Fax Card
134-210 Fax Controller Parameter RAP ......................................................................... 2-715
134-211 FAX PWB RAP ................................................................................................. 2-715
202 Timer
202-399 Internal Timer RAP ........................................................................................... 2-717
Other Faults
OF 1 Paper Size Mismatch In Width RAP....................................................................... 2-719
OF 2 Size Switch Assy RAP ........................................................................................... 2-719
OF 3 Main Drive Assy RAP............................................................................................. 2-721
OF 4 Dark / Blank Display RAP ...................................................................................... 2-721
service-repair-manual.com

Xerox WorkCentre 5222 Specifications

General

AC input voltage	100 - 127 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	3 W
Power consumption (standby)	95 W
Power consumption (average operating)	605 W
Depth (imperial)	25.7 \
Finishing option	Yes
Width (imperial)	25.2 \
Height (imperial)	43.1 \
Scan file formats	TIFF, PDF, XPS
Minimum storage drive space	40 GB
Maximum media size (WxH) (imperial)	11.7 x 17 \
Minimum media size (WxH) (imperial)	5.5 x 8.3 \
Processor frequency	333 MHz
Card reader integrated	No
Sound power level (standby)	22 dB
Paper input type	Paper tray
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Total number of input trays	2
Maximum number of input trays	4
Auto document feeder (ADF) input capacity	75 sheets
Print technology	Laser
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	54.8 ipm
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A3)	13 ppm
Print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4, 8
Optical scanning resolution	- DPI
PCL fonts	81
Printer fonts	PCL, PostScript
Printing colors	Black
Stapling capacity	50 sheets
Maximum duty cycle	70000 pages per month
Recommended duty cycle	0 - 12000 pages per month
Number of PostScript fonts	136
Page description languages	PCL 5e, PCL 6
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SNMP
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols (IPv6)	EtherTalk, FTP, HTTP, HTTPs, LPR, SNMPv1, SNMPv2, SNMPv3, TCP/IP
Paper tray media types	Bond paper, Heavy paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight	60 - 105 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Multi-purpose tray media types	Bond paper, Envelopes, Hole punched paper, Labels, Letterhead, Plain paper, Recycled paper, Transparencies
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Paper tray media weight (imperial)	16 - 28 lbs
Auto Document Feeder (ADF) media weight	38 - 128 g/m²
Multi-Purpose Tray media weight (imperial)	16 - 80 lbs
Auto Document Feeder (ADF) media weight (imperial)	16 - 32 lbs
Display	LCD
Product color	White
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.3 Panther, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard
Linux operating systems supported	SuSE Linux 10, SuSE Linux 10.2, SuSE Linux 10.3
Other operating systems supported	Solaris 10, Solaris 8, Solaris 9
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Certification	FCC, 89/336/EEC, UL, CB, 73/23/EEC, GOST, NOM, ISO 15408
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Depth	654 mm
Width	640 mm
Height	1114 mm
