26
Quick Use Guide
Replacing the Drum Cartridge
1. Make sure the machine is not in operation and open the front cover.
2. Open Tray 5 (Bypass) and then Cover A while lifting up the release
lever.
3. Lift up the colored lever, and slide the drum cartridge out until you can
grasp the handle on top of the cartridge.
