Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-10
Item Part Name Part Number
1. ROLL ASSY FEED MSI (with 2-7) 059K 75531
2. CAM MSI R 008E 97492
3. ROLL CORE MSI --
4. ROLL ASSY FEED 059K 75520
5. HOLDER FEED --
6. SHAFT FEED --
7. CAM MSI L 008E 97481
8. HOLDER BTM R --
9. PLATE ASSY BOTTOM (with 27,28) --
10. HOLDER BTM L --
11. HOLDER ASSY SEPARATOR (with 29-31) 019K 11790
12. SPRING SEPARATOR 809E 91661
13. FOLLOWER R 008E 97513
14. FOLLOWER L 008E 97503
15. -- --
16. -- --
17. ARM MSI L 031E 98380
18. SPRING NF 809E 91681
19. -- --
20. -- --
21. -- --
22. -- --
23. -- --
24. ARM MSI R 013E 98390
25. -- --
26. -- --
27. PLATE BOTTOM --
28. PAD MSI --
29. CLUTCH ASSY FRICTION --
30. ROLL ASSY SEPARATOR --
31. HOLDER SEPARATOR --
To Next Page
