Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-2
Serial Number Location and Format
Changes to Xerox products are made to accommodate improved components as they become
available. It is important when ordering parts to include the following information:
• Component's part number
• Product type or model number
• Serial Number of the printer
The serial number is found on a label located on the left side frame near the Fuser. The Front
Cover must be opened to view the Serial Number.
The nine-digit serial number uses the format PPPRSSSSS.
• PPP = Three digit alphanumeric product code (example)
Product Code Product
P3A 6020, 110V Engine
P4A 6020, 220V Engine
P5A 6022, 110V Engine
P6A 6022, 220V Engine
P0B 6025, 110V Engine
P9A 6025, 220V Engine
s6020-211
MANUFACTURED: March, 2011
Xerox S/N: YXN000524
