Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-6
PL Item Part Name Part Number
1. COVER ASSY TOP (WITH 2-4,23) (TOP COVER) 848K 93531
2. TRAY EXTENSION CBV 050E 26771
3. PANEL ASSY LED LT REF only
4. COVER ASSY TOP FRONT WPS LQ REF only
5. - --
6. COVER ASSY REAR 640K 93720
7. BEARING BTR L 013E 38091
8. BEARING BTR R 013E 38101
9. ROLL ASSY BTR 022K 78520
10. KIT COVER REAR INNER LQ 604K 92560
11. -- --
12. SWITCH I/L ASSY (with 13) 676K 12440
13. HOLDER IL REAR --
14. -- --
15. COVER WINDOW TNR 848E 67341
16. HINGE CVR SFP 803E 06441
17. KIT COVER MSI LQ 604K 92570
18. KIT COVER FRONT LQ 604K 92580
19. -- --
20. -- --
21. COVER SIDE L LQ 848E 67322
22. -- --
23. COVER TOP REAR --
24. COVER INNER TOP --
25. COVER OPP 822E 10600
26. PWB ASSY LED 101K 68030
To Next Page
