Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-78
Item Part Name Part Number
1. ROLL ASSY FEED MSI (WITH 2-7) 059K 88840
2. CAM MSI R 008E 97492
3. ROLL CORE MSI --
4. ROLL ASSY FEED 059K 78701
5. HOLDER FEED --
6. SHAFT FEED --
7. CAM MSI L 008E 97481
8. HOLDER BTM R --
9. HOLDER BTM L
10. HOLDER ASSY SEPARATOR (WITH 22-24) 019K 16020
11. SPRING SEPARATOR 809E 91661
12. FOLLOWER R 008E 97513
13. FOLLOWER L 008E 97503
14. ARM MSI L 031E 89680
15. SPRING NF 809E 91681
16. ACTUATOR NO PAPER 120E 35360
17. COVER NO PAPER 019E 89720
18. SENSOR PHOTO (NO PAPER SENSOR) 930W 00123
19. ARM MSI R 019E 89690
20. HARNESS ASSY RKN SNS (J12,-J20,J121,J122) --
21. PLATE BOTTOM TIE --
22. CLUTCH ASSY FRICTION --
23. ROLL ASSY SEPARATOR --
24. HOLDER SEPARATOR --
25. ARM BOTTOM IN L
26. ARM BOTTOM IN R --
27. PLATE ASSY SEPERATOR --
28. SLIDE STOPPER --
29. SPRING STOPPER --
30. SPRING ACTUATOR NO PAPER MAIN --
31. SPRING ACTUATOR NO PAPER SUB --
32. ACTUATOR NO PAPER SUB --
33. PLATE ARM L --
34. PLATE ARM R --
To Next Page
