7
Method 3:
1. Reset the satellite router to the factory seings, and then
power it on. Wait for the satellite router's system indicator to
turn blue or white (the indicator's color depends on the
specific model).
2. Connect the network cable to the satellite router's WAN port
and the main router's LAN port, then the Internet indicator
will begin to blink quickly (two blinks per second), indicating
the Mesh networking starts.
3. When the Internet indicator of the satellite router remains lit,
the Mesh networking is successfully completed.
Satellite Router Main Router
Internet
WAN
Port
LAN
Port

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xiaomi AX3000 and is the answer not in the manual?

Xiaomi AX3000 Specifications

General IconGeneral
Wi-Fi StandardWi-Fi 6 (802.11ax)
Frequency Bands2.4 GHz, 5 GHz
Antennas4 external antennas
RAM256 MB
Flash Memory128 MB
MU-MIMOYes
OFDMAYes
Ports1x WAN, 3x LAN
ProcessorDual-core CPU
Mesh NetworkingYes
SecurityWPA3
Maximum Throughput3000 Mbps (574 Mbps on 2.4 GHz + 2402 Mbps on 5 GHz)
