Xilinx Alveo U200 User Manual

IMPORTANT! Ne débranchez pas le connecteur auxiliaire d'alimentaon des cartes Alveo™ pendant
qu’elles sont sous-tension (“hot-plug” n'est pas autorisé).
WICHTIG! Trennen Sie den Alveo™-Stromanschluss-Stecker nicht im eingeschalteten Zustand (Hot-Plug
ist nicht zulässig).
The following procedure is a guide for the Xilinx
®
Alveo™ data center accelerator card
installaon. Consult your computer documentaon for addional informaon.
If you encounter any issues during installaon, see Chapter 7: Troubleshoong and Known
Issues. Also see AR-71752 for addional known issues.
1. Host power supply must be disconnected.
2. For enclosed computers, open your computer by removing the casing.
3. If necessary, remove the two adjacent PCIe
®
slot covers corresponding to the PCIe x16 slot
in which you are installing the Alveo card.
4. Plug the Alveo card in the PCIe x16 slot on the motherboard.
5. Connect the AUX power connector to the Alveo card, ensure the plug is mechanically xed
(with the click).
IMPORTANT! Operaon of the Alveo cards only with AUX power connector is not allowed.
IMPORTANT! Le fonconnement des cartes Alveo uniquement avec le connecteur auxiliaire n'est pas
autorisé.
WICHTIG! Der Betrieb von Alveo-Karten nur mit AUX Connector ist nicht zulässig.
The Alveo card has an 8-pin female PCIe AUX power connector. Depending on your server or
computer, an addional PCI Express auxiliary power cable or adapter may be needed. Consult
your computer documentaon for addional informaon.
For acvely cooled cards, connect the power cable to the AUX power connector at top of the
card as shown in the following gure.
Chapter 3: Card Installation Procedures
UG1301 (v1.8) February 5, 2021 www.xilinx.com
Getting Started with Alveo Accelerator Cards 16
Send Feedback
