KCU105 Hardware Setup
Connect a USB Type-A to Micro-B
cable to the USB UART connector
(J4) on the KCU105 board
Connect a USB Type-A to Micro-B
cable to the USB JTAG (Digilent)
(J87) connector on the KCU105
board
Connect the Ethernet cable to P3
Connect these cables to your PC
Note: Presentation applies to the KCU105
