Figure 11: SmartLynq+ to HSDP on a Target Board
The following table and gures show two opons for the HSDP interface. Note that each opon
has tradeos that must be considered by the end user. For the greatest observability use opon
1. For reduced observability use opon 2. The table provides a quick summary with the pros/
cons of the various opons.
Table 6: HSDP Interface Options
Option Description Pro Con
1 HSDP with FTDI JTAG One connector integrates all essential
debug observability
Extra cost incurred by by FTDI and related
support parts/power
2 HSDP with PC4 JTAG Lower cost and reduced real estate No integrated UART support
Chapter 9: HSDP Target Interface
UG1514 (v1.0) March 8, 2021 www.xilinx.com
SmartLynq Module+ 29
Send Feedback
