Xilinx Spartan-6 User Manual

Spartan-6 FPGA GTP Transceiver SIS Kit (HyperLynx) www.xilinx.com 11
UG396 (v1.0) June 10, 2010
Getting Started
2. Make the desired changes to any of the parameters, and press the OK button to exit.
This writes the necessary configuration files for the simulation.
Note:
The frequency of the pulse train or the time of the bit interval specified in the oscilloscope
must match the Data rate setting in the TX configurator (see Figure 1-3). Each setting must be
done explicitly.
X-Ref Target - Figure 1-3
Figure 1-3: Configure Spartan-6 FPGA GTP Transmitter
UG396_c1_03_042010

Xilinx Spartan-6 Specifications

General

Maximum Transceiver Data Rate	3.2 Gbps
Number of Transceivers	Up to 8
Supported Protocols	Ethernet
Power Supply	1.0V, 2.5V, 3.3V
Operating Temperature	0°C to +85°C (Commercial), -40°C to +100°C (Industrial)
Transceiver Type	Multi-Gigabit Transceivers (MGTs)
