XP3 PLC/HMI Hardware Manual Page 8 of 42 LMAN007_R2V2

The cut-out size when installing:
Note:
1. The fixing screws shouldn’t be too tight to avoid damaging the panel.
2. The four fixing screws should be under equal pressure.

1-6 Dimensions and installation
164
113
