XM SureConnect User Manual

Installation Setup Overview for both Options 1 and 2
Installation Setup
7
no boot necessary
glass
inside your
vehicle
outside
car dock
XM car
antenna
coupling
clip
coupling
module
input
cable
output
cable
External AntennaConnecting the Components Internal on-glass antenna
boot
power
XM antenna
or
Figure 1a Figure 1b Figure 1c
Option 1 Option 2
Common connections
for both options 1 and 2
on-glass
contact bracket
