INSTRUCTION
EN
6.2.2.2 Installed in forward facing position with ISOFIX
connector, Belt and Top Tether
Put the ISOFIX insert guide into the two ISOFX
attachment points of your vehicle.
If you don't have ISOFIX insert guide, please ignore this
step.
NOTE: The ISOFIX attachment points are located
between the surface and the backrest of the vehicle seat.
Press the ISOFIX button to pull out the two locking arms
from the base bottom. Pull the locking arm to and fro until
you hear an audible CLICK which indicates they are fully
engaged. And on both sides of the locking arm’s button
turn into green safety color.
Pull out the top tether and press the release button, pull
the top tether long enough to hang the latch on the back
of the car seat.
Fix the latch on the fixed point,and the position of the
fixed point are shown in the picture (one of the three
positions). Make sure the top tether clip is tightened up.
First pull out the belt from the belt ALR. Diagonal belt
through the same side of belt guidance , lap belt
through the same side of belt guidanceΏ , then pull
the diagonal belt and lap belt together through another
side of belt guidanceΏ.
NOTE: Keep the diagonal belt at the position of
shoulder between the outside of the neck and
shoulder( Middle of point A and B ).(see p27 picture a)
Lock the tip of the buckle into the vehicle seat buckle
with a CLICK noise. Follow the direction of arrow to
tighten belt, and put redundant belt into cloth cover.
Shake the child safety car seat to make sure it is
securely attached.
CAUTION! The diagonal seat belt section must run
diagonally backward. You can adjust the course of the
belt with your vehicle's adjustable belt deflector on
both sides
a
A
B
Ensure the lap
belt is as close as
possible to lower.
Ensure the lap
belt is on the
pelvis, not on the
abdomen.
CLICK
7. CARE AND MAINTENANCE
CLEANING THE BUCKLE
Periodically inspect your child seat for worn or
damaged parts. If damaged parts are found,
replace the child seat Keep the child seat clean Do
no lubricate any parts of the child seat.
To prolong the life of your nursery product, keep it
clean and do not leave it in direct sunlight for
extended periods of time.
Removable fabric covers and trims may be cleaned
using warm water with a household soap or a mild
detergent. Allow it to dry fully, preferably away from
direct sunlight.
Food, drink, or other debris may collect inside the
harness buckle which can affect proper functioning
Wash in warm water until clean. Be sure you can
hear an audible click to make sure the buckle is
working properly.
