Xomax S64 - 5.7 Removing Harness and Pads

p
Step 1: Turn the child safety seat to the back,
According to the sequence of ΍ΎΏ in picture A, the two
shoulder belts from the metal link.
Remove the shoulder belt from the harness connector,
according to ΐΑ in picture A,
storage metal link to metal link area on the behind of the
backrest. shown in picture C.
Then pull out the shoulder belt and harness from the seat
hole, so that the shoulder belt and harness can be
removed.
Then pull out the shoulder belt from the buckle on the front
of the seat, And remove the sleeping pad , shoulder pad
and buckle. Finally put redundant belt into cloth cover.
(Picture B)
p

INSTRUCTION
EN

Fifth Level (Lying Level)
First Level
Second Level
Third Level Fourth Level
Installation of
rearward facing
Installation of forward facing
Group 0+I(0-18kg) Group I(9-18kg)
Group II III
(15-36kg)
5




5.7 Removing 5-Point Harness ,
sleeping pad and 5-piont harness
A
B
C
