Page 16
Rev.: 20160608
Platform: DBALL/DBALL2
Firmware: CHRYSLER3 Remote Start Ready (RSR) Installation
© 2016 Directed. All rights reserved.
Flashes Diagnostic
1 Runtime expired.
2 Over-rev shutdown.
3 Low/No RPM.
4 Transmitter shutdown.
5 Brake shutdown.
6 Hood shutdown/Remote start safety override switch is ON*.
7 Remote start safety override switch is ON*.
The parking lights on your vehicle will flash a specific number of times 3 seconds following an unscheduled shutdown or
failure to start. Each flashing pattern is described below.
* If the vehicle hood status is supported through data, safety override switch input will report 7 flashes.
Parking Light Error Codes
LED Description Troubleshooting
D2D and W2W commands
LOCK command received.
UNLOCK command received.
TRUNK command received.
RSR Code
3x OEM Lock Remote Start
Activation was attempted when RFTD
feature is disabled.
Activated from Web automatically when using RSR flash tool
or can be done manually. Refer to feature programming
section for more information.
If the bypass module fails to flash, it means the module did
not receive the signal. Commands can come from RF, D2D or
W2W.
Flashes
red x7
Flashes
orange
x1
Flashes
orange
x2
Flashes
orange
x3
