Xpresskit DBALL2 Installation

Rev.: 20160608
Platform: DBALL/DBALL2
Firmware: CHRYSLER3 Remote Start Ready (RSR) Installation
© 2016 Directed. All rights reserved.
Type 2 - Vehicle Wiring Reference Charts
Page 8
Wire colors should only be used as a reference. You should always test a wire's function and pin location before
connecting to it. For more detailed information on wiring connections, visit www.directechs.com.
Function Color Pin Polarity Location Color Pins
HS CAN High Gray/White 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Yellow 14 Data OBDII diagnostic connector. Black 16
HS CAN2 High Gray 3 Data OBDII diagnostic connector. Black 16
HS CAN2 Low White 11 Data OBDII diagnostic connector. Black 16
Immobilizer Data White/Lt. Green 5 Data Keyless Ignition node, located at Start/Stop button. Black 6
PTS (Push-To-Start) Violet/Brown 4 (+) Keyless Ignition node, located at Start/Stop button. Black 6
Parking Light MUX White/Brown 1 MUX Headlight Switch Black 10
12V Red or Red/Yellow 3 (+) C2 connector, at BCM located in the driver dash. Lt. Gray 4
HS CAN High Gray/White 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Yellow 14 Data OBDII diagnostic connector. Black 16
HS CAN2 High Gray 3 Data OBDII diagnostic connector. Black 16
HS CAN2 Low White 11 Data OBDII diagnostic connector. Black 16
Immobilizer Data White/Lt. Green 5 Data Keyless Ignition node, located at Start/Stop button. Black 6
PTS (Push-To-Start) Violet/Brown 4 (+) Keyless Ignition node, located at Start/Stop button. Black 6
Parking Light MUX White/Brown 1 MUX Headlight Switch Black 10
12V Red or Red/Yellow 3 (+) C2 connector, at BCM located in the driver dash. Lt. Gray 4
HS CAN High Gray/White 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Yellow 14 Data OBDII diagnostic connector. Black 16
HS CAN2 High Gray 3 Data OBDII diagnostic connector. Black 16
HS CAN2 Low White 11 Data OBDII diagnostic connector. Black 16
Immobilizer Data White/Lt. Green 5 Data Keyless Ignition node, located at Start/Stop button. Black 6
PTS (Push-To-Start) Violet/Brown 4 (+) Keyless Ignition node, located at Start/Stop button. Black 6
Parking Light MUX White/Brown 1 MUX Headlight Switch Black 10
12V Red or Red/Yellow 3 (+) C2 connector, at BCM located in the driver dash. Lt. Gray 4
HS CAN High Gray/White 6 Data OBDII diagnostic connector. Black 16
HS CAN Low Yellow 14 Data OBDII diagnostic connector. Black 16
HS CAN2 High Gray 3 Data OBDII diagnostic connector. Black 16
HS CAN2 Low White 11 Data OBDII diagnostic connector. Black 16
Immobilizer Data White/Lt. Green 5 Data Keyless Ignition node, located at Start/Stop button. Black 6
PTS (Push-To-Start) Violet/Brown 4 (+) Keyless Ignition node, located at Start/Stop button. Black 6
Parking Light MUX White/Lt. Green 1 MUX Headlight Switch Black 10
12V Red or Red/Yellow 3 (+) C2 connector, at BCM located in passenger kick panel. Lt. Gray 4
Wire Information Connector Information
Dodge Ram 1500 (Smart Key) 2013-2016
Dodge Ram 2500 (Smart Key) 2013-2016
Jeep Grand Cherokee (Smart Key) 2014-2016
Dodge Ram 3500 (Smart Key) 2013-2016
