46
903312
SFH M3x12
960030
N M3
901302
SB M3x2.5
902256
SH M2.5x6
Premarked holes to
REDUCE DOWNFORCE.
Wickerbill plate to
INCREASE DOWNFORCE.
#107602 HUDY Reamer for Body 0-18mm + Cover - Large
#107601 HUDY Reamer for Body 0-9mm + Cover - Small
To tighten the setscrew you can also use the
HUDY 17mm Wheel Nut Tool #107570.
Servo screw
(NOT INCLUDED)
Ensure that the servo is in neutral position
before attaching the servo horn.
XRAY STARBURST WHEELS
#359808 Pink OPTION
#359809 Yellow OPTION
DETAIL
WINGS
#353517-K BLACK INCLUDED
#353517 WHITE OPTION
#353517-Y YELLOW OPTION
#353512 LEXAN
®
OPTION
NOTE
ORIENTATION
HUDY REAR WING SHIM
#293561 SILVER OPTION
#293561-O ORANGE OPTION
#293561-K BLACK OPTION
#353561 SILVER OPTION
WHEEL NUTS
#355261 OPEN RIBBED INCLUDED
#293560 COVERED RIBBED OPTION
#355265 COVERED OPTION
