36
XT8XT8E
ACKERMANN
BUMP STEER
TOE-IN
Right thread
Left thread
70.5mm
70.5mm
Left thread
Left thread
Right thread
Right thread
Right thread
Left thread
HOLD
HOLD
DETAIL
Install the pivot balls with Professional
Multi Tool (HUDY #183011).
Install the pivot balls with Professional
Multi Tool (HUDY #183011).
7. STEERING
960030
N M3
303123
SHIM 3x6x2
L=R
2x
2mm
Check for free
movement.
Check for free
movement.
INITIAL POSITION
902312
SH M3x12
NOTE ORIENTATION
Adjustment block towards outside
NOTE ORIENTATION
Adjustment block towards outside
BOOK
SET-UP
