8
FB160 Folding Bike
Handlebar
4
1. Remove 4 Screw Sets (No. 12) from the Handlebar Tube (No. 04).
2. Connect the Middle Sensor Wire (No. 19) with the Console (No. 08).
3. Attach the Handlebar Tube (No. 04) to the Rear Support Tube (No.
02), and tighten with 4 Screw Sets (No. 12).
72
04
08
19
12
02
08
19
Allen Key

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xterra FB160 and is the answer not in the manual?

Xterra FB160 Specifications

General IconGeneral
Resistance Levels8
Resistance TypeMagnetic
DisplayLCD
Product Weight41 lbs
PedalsSelf-Balancing with Adjustable Straps
FoldableNo
Seat TypePadded
Transport WheelsYes
Heart Rate MonitoringGrip sensors
Dimensions32.5" L x 19" W x 46.5" H
