DyacoCanadaInc2017

25


Key PartNumber Description Qty
41 7615041 Magnetassembly 1
42L/R 7615042L/R Chaincover(L/R) 1set
43 7615043 Crankcover 2
44 7615044 Powderbushing 2
45 7615045 Self‐tappingscrew 6
46 7615046 HexHeadboltM8*55 1
47 7615047 CarriageboltM8*40 1
48 7615048 Squareplate 1
49 7615049 Spacer 1
50 7615050 Idlerwheel 1
51 7615051 Sensorbracket 1
52 7615052 HexheadboltM6*25 1
53 7615053 HexheadnutM6 2
54 7615054 Flangenut 2
55 7615055 Belt 1
56 7615056 Bearingassembly 1set
57 7615057 Sensorwire 1
58 7615058 Flywheel 1
59 7615059 Springformagnetassembly 1
60 7615060 Motor 1
61 7615061 Powderwire 1
62 7615062 Beltpulley 1
63 7615063 Motorcable 1
64 7615064 Springforbelt 1
65 7615065 Eyebolt 1
66 7615066 NutM8 1
67 7615067 Metalbushing 1
68 7615068 NutM10 3
69 7615069 Tapertypemetalbushing 1
70 7615070 Bearing6000 3
71 7615071 Bearing6900 1
72 7615072 Axleforflywheel 1
73 7615073 Cooperwasher 1
74 7615074 Springclutch 1
75 7615075 Smallbeltpulley 1
76 7615076 Bottleholder 1
77 7615077 Adapter 1
78 7615078 Allenkey6mm 1
79 7615079 Boxwrench 1


