UB150

ASSEMBLYINSTRUCTIONS

1FRONTANDREARSTABILIZER

15
13
16
15
13
16
1
2
3


1. Attachfrontstabilizer(2)tomainframe(1),tightenwith2
setsofAllenbolt(15),springwasher(13)andcurved
washer(16).
2. Attachrearstabilizer(3)tomainframe(1),tightenwith2
setsofAllenbolt(15),springwasher(13)andcurved
washer(16).
2CONSOLESUPPORT
1
34
16
18
16
18
4
33


1. Takefrontpost(4)andconnectuppercomputerwire
(33)withlowercomputerwire(34).Insertfrontpost(4)
intomainframe(1)andtightenwith4setsofAllenbolt
(18)andcurvedwasher(16).

Hardware Step1
4 Allen bolt (#15)
4 Spring washer (#13)
4 Curved washer (#16)
Hardware Step 1
Hardware Step 2
4 Allen bolt (#18)
4 Curved washer (#16)
