Xterra UP150 - Assembly Pack Checklist

customerservice@dyaco.ca
DyacoCanadaInc2017

8

UB150

ASSEMBLYPACKCHECKLIST

PartNo. Description Q'ty
11 QuickReleaseKnob 1
13 SpringWasherΦ8 4
15 AllenBoltM8*75 4
16 CurvedWasherΦ8*Φ20 8
18 AllenBoltM8*16 4
21 TTypeKnob 1
37 ClampCover 1
78 AllenKey6mm 1
79 BoxWrench 1

Note:Abovepartsareallthepartsneededtoassemblethismachine.Beforeyoustarttoassemble,
pleasecheckthehardwarepackingtomakesuretheyareincluded.






















