-33-
Waterproof
Case
Helmet
Base
1
1
3
3
2
2
+ +
Method B:
Waterproof
Case Mount
Step 1: Interlock the mounting fingers on the Waterproof
Case with the mounting fingers on the Waterproof Case
Mount, and then secure them with a screw.
Step 2: Slide the Helmet Base into the Waterproof Case
Mount bottom until it clicks into place.
Step 3: Stick the Adhesive Pads on the bottom of the
Helmet Base. Find a suitable position and fix the camera on
the helmet.
