Technical specifications
Construction type
Integrated amplifier
Dimensions
158 x 445 x 468 mm (HxWxD)
Inc Feet & Terminals
Weight
22 kg
27kg including cardboard box
Frequency response
5 Hz- 50kHz (non-flatness < 0.5dB)
SNR Ratio
>100dB (A Weighted, 100W, 8ohm)
Impedance (input)
20 kOhms
Voltage gain
42dB
Damping factor
>100
AC Power supply
~220-240V & ~110-130V
POWER
2x50W 8 Ohm (Class A)
2x110W 8 Ohm
2x180W 4 Ohm
2x300W 2 Ohm
Connections
Gold plated RCA,
Speaker output: Banana /Pole screw
Volume handling
Crystal chip CS3310 for volume control in
0,5dB
steps
DAC
Analog Devices AD1955
