XTZ EDGE A2-300 - Power and Signal Sense; Power; INPUT; OUTPUT; STEREO & MONO

7
INPUT
- L RCA input for the Left amplification channel.
- R RCA input for the Right amplification channel.
- GAIN Potentiometer for trimming the input amplification gain.
Power
- AC Power inlet AC Power input and FUSE compartment.
- Fuse Do only replace with “T4AH 250V” rated fuse.
- Power Switch Main power switch (toggle).
OUTPUT
- L Plus (+) Pole and Minus (-) Pole output connector for Left channel.
- R Plus (+) Pole and Minus (-) Pole output connector for Right channel.
STEREO & MONO
- STEREO Left and Right channel are separated.
- MONO Left and Right channel are summed up.
Signal Sense
- AUTO ON The amplifier powers on when a signal is present and goes into standby
mode when there is no signal anymore.
- ALWAYS ON The amplifier is always turned on and will not switch to standby
mode.
