STEREO or BRIDGED
- BRIDGED/BTL Set to Bridged/BTL for bridged mono operation.
IMPORTANT: CLASS 2 WIRING
EDGE A2-400 power amplifier requires Class 2 output wiring.
Turn the main power switch off when connecting or disconnecting the speaker wires.
OUTPUT +
- BTL Plus (+) pole output connector when in bridged/BTL mode.
OUTPUT -
- BTL Minus (-) pole output connector when in bridged/BTL mode.
INPUTS
- RCA Use single RCA when input signal is unbalanced RCA.
- XLR Use single XLR when input signal is balanced XLR.
