Speaker
Placement
To achieve the best results the front speakers should be placed symmetrically in front of the listener. The
distance between the front speakers should be about 80% of the distance to the listener. In other words,
the recommended angle for the front speakers is 45°.
Finally
Please remember that good sound is a matter of taste, so you have to experiment to obtain your favorite
sound. We wish you best of pleasure.
The EDGE A2-400 is designed to deliver high performance with easy management.
Auto On /
Trigger
When the unit is set to “Auto On” mode, the amplier requires a constant signal to stay on. In absence of
a signal the amplier switches to standby mode after > 10 minutes.
If set to “Trigger” the amplier will stay in standby mode until it detects a +12V trigger signal on the trigger
minijack input connector.
Standby
In standby mode the whole unit consumes less than 0.3 W (EU mains) which surpasses the requirements
of the “one watt initative 2013” by IEA “International Energy Agency “.
Front LED
Red LED: Device is in standby mode and waiting for an input signal or trigger signal to turn on.
Green LED: Device is on.
Blue LED: Clipping indicator (blinking).
Adjustable Gain
The gain control can be used to match the total output level with other ampliers and/or other speakers
in your system. Using the adjustable gain will limit the maximum output level of the device and possibly
protect your speakers from damage when playing loud.
Stereo / Bridged
- Use the stereo mode when using the amplier in a regular stereo system.
- Use the bridged/BTL mode when using the amplier with a single speaker.
Operating the EDGE A2-400
