XTZ EDGE A2-400 - Inputs & Outputs (2;2); Power and Loop Out Connectors; Speaker and Input Connectors

98
LOOP OUT
- L RCA loop out from Left channel input.
- R RCA loop out from Right channel input.
XLR INPUT: Balanced
- L Balanced input for the Left amplification channel.
- R Balanced input for the Right amplification channel.
RCA INPUT: Unbalanced
- L Unbalanced input for the Left amplification channel.
- R Unbalanced input for the Right amplification channel.
POWER
- POWER SWITCH Main power switch (toggle).
- AC POWER INLET CLASS II AC power input.
- FUSE Do only replace with “T6.3Ah 250V” rated fuse.
OUTPUT
- L Plus (+) pole and Minus (-) pole output connector for Left channel.
- R Plus (+) pole and Minus (-) pole output connector for Right channel.
IMPORTANT: CLASS 2 WIRING
EDGE A2-400 power amplifier requires Class 2 output wiring.
Turn the main power switch off when connecting or disconnecting the speaker wires.
