7
INPUTS
- RCA Left RCA input for the Left channel. (Left & Right channels are a sum).
- RCA Right RCA input for the Right channel.
- XLR IN Balanced input.
- XLR Pass through Signal pass through from balanced input.
MAIN CONTROLS
- Frequency Select the subwoofers upper frequency limit.
- Phase Correct the phase between your main speakers and subwoofer/-s.
- Gain Calibrate the subwoofers output volume.
ADVANCED CONTROLS (PARAMETRIC EQUALIZER)
- PEQ Frequency Target frequency for filter effect.
- PEQ Gain Controlling the level of cut or boost (-9 to +9 dB).
- PEQ On/Off Select between Active(On) or Bypass(Off) mode.
Power INPUT
- AC Power inlet AC Power input and FUSE compartment.
- Fuse Do only replace with “T4AH 250V” rated fuse.
- Power Switch Main power switch (toggle).
